MFKDSP/ 7-5,08 is a 5.08mm pitch 7 position terminal block from PHOENIX CONTACT, with a rated current of 12 A and a rated voltage of 250 V. It is spring-cage connected and can be soldered.
The MFKDSP/7-5,08 is a spring‑cage terminal block with a 5.08 mm pitch and 7 positions. It is designed for solder‑on assembly and supports a nominal current of 12 A at 250 V. The device is green, RoHS‑compliant and includes detailed mechanical dimensions.
The datasheet lists electrical ratings such as a 4 kV surge voltage, 320 V/630 V rated voltages, and provides certification information (CSA, CUL, UL, GOST). Accessories like marker cards and plug adapters are also described.
| Nominal current | 12 A |
|---|---|
| Nominal voltage | 250 V |
| Pitch | 5.08 mm |
| Number of positions | 7 |
| Overall width (dimension a) | 30.48 mm |
| Color | green |
The terminal block is rated for a nominal current of 12 A.
It has 7 positions.
The pitch is 5.08 mm.
It is certified by CSA, CUL, UL and GOST.
