This document introduces the PC terminal block product from PHOENIX CONTACT GmbH & Co. KG. The product has a rated current of 2A and a rated voltage of 160V. The pin spacing is 2.5mm and it has 2 positions. The connection type is spring-cage connection and it can be installed by soldering. It is green in color and has offset soldering legs and a two-row structure. The product is compliant with WEEE/RoHS standards.
The PTSA 0,5/2-2,5-Z is a 2‑position spring‑cage terminal block with a 2.5 mm pitch, designed for 2 A nominal current and 160 V nominal voltage. It features a green housing, offset soldering legs, and a two‑row layout suitable for PCB mounting.
The sheet provides dimensions, electrical ratings, material specifications, and certification information, along with drawing references for drilling and solder pad geometry. Contact details for Phoenix Contact and ordering information are also included.
| Nominal current | 2 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 2.5 mm |
| Number of positions | 2 |
The nominal current is 2 A.
The pitch is 2.5 mm.
