This document describes the features and characteristics of Bulgin brand's Crocodile Clips and Terminals products, including information about materials, sizes, and maximum ratings.
This leaflet presents Bulgin's range of CR series crimp connectors, TX series panel terminals and KX series grub screws. For each part the current and voltage ratings, material finishes, overall length and jaw grip dimensions are provided.
The document also includes fixing details, temperature limits and ordering information such as list numbers and colour options. All data are given in metric units and reference Bulgin's UK contact details.
| Voltage rating | 3.5kV ac to panel |
|---|---|
| Clip material | Steel, Bright Zinc Passivated |
| Moulding material | High Impact Polystyrene |
| Temperature range | -20°C to +60°C |
The clip is made of steel with a bright zinc passivated finish.
TX0100 terminals are rated for 3.5 kV ac to the panel.
They operate from –20 °C up to +60 °C.
