BUCCANEER USB is an IP68 rated USB connector that is compatible with USB2.0 protocol. It supports hot-plugging and has dust and waterproof functions. The connector has single-ended and double-ended types, and is available in three lengths: 2m, 3m and 5m.
The USB Buccaneer IP68 series from Bulgin provides rugged A‑type and B‑type USB connectors for panel‑mount applications. Part numbers such as PX0840, PX0841, PX0842 and PX0848 cover various cable lengths and mounting styles, including front‑panel and rear‑panel configurations.
Technical data sheets list current and voltage ratings, contact resistance, USB version, material construction and environmental ratings. Sealing caps and cable adapters are also detailed for complete system integration.
| Current rating | 1 A |
|---|---|
| Voltage rating | 30 Vac (RMS) |
| Contact resistance | <10 mΩ max |
| USB version | 2.0 |
| PCB pitch | 2.54 mm |
| Shell material | Steel |
| Shell plating | Nickel |
| Contact plating | 30 µin Gold |
| Operating temperature | O°C to +70 °C |
| Mating cycles | 1,000 |
| RoHS compliance | Compliant |
| Cable jacket material | PYC black |
| Conductor gauge | 4 × 28 AWG |
The connectors are rated for a maximum current of 1 A.
They are rated for 30 Vac (RMS).
The series uses USB version 2.0.
They operate from O°C up to +70 °C.
