The document describes the features and characteristics of the Super Bright Red light-emitting diode, including 8mm diameter big lamp, wide viewing angle, compatibility with integrated circuits, reliable and rugged, long life-solid state reliability, and RoHS compliance.
The WP793SRD/E is a super‑bright red 8 mm round LED from Kingbright. It offers a wide viewing angle, high luminous intensity and solid‑state reliability, and meets RoHS requirements. The package dimensions are 1.5 mm × 1.5 mm × 1.5 mm (typical) with a 0.7 mm lead length.
Key electrical and optical characteristics include a 660 nm peak wavelength, 1.85 V forward voltage at 20 mA, 10 µA reverse current at 5 V, and a maximum continuous forward current of 30 mA (155 mA peak). The device operates from –40 °C to +85 °C and is supplied in 200‑piece bags or 1 K‑piece boxes.
| Peak Wavelength | 660 nm |
|---|---|
| Power Dissipation | 100 mW |
| DC Forward Current | 30 mA |
| Operating Temperature Range | -40 °C to +85 °C |
The LED has a peak wavelength of 660 nm.
Yes, the device is RoHS compliant.
The continuous forward current rating is 30 mA, with a peak forward current rating of 155 mA.
