ORANGE 5mm LED LAMP WP483EDT is a high performance LED product produced by Texas Instruments, its features are low power consumption, high reliability, rugged, long life.
The WP483EDT is a 5 mm cylindrical LED lamp in an orange color, featuring low power consumption, rugged reliability, and availability on tape and reel. It complies with RoHS and is designed for long‑life solid‑state operation.
The datasheet provides a selection guide, optical and electrical characteristics, absolute maximum ratings, and derating curves. Key parameters such as peak wavelength, forward voltage, and luminous intensity are listed, along with temperature limits and recommended soldering conditions.
| Peak Wavelength | 627 nm |
|---|---|
| Dominant Wavelength | 625 nm |
| Spectral Line Half‑width | 45 nm |
| Capacitance | 15 pF |
| Forward Voltage (typ.) | 2.0 V – 2.5 V @ 20 mA |
| Reverse Current | 10 µA @ 5 V |
| Power Dissipation | 105 mW |
| DC Forward Current | 30 mA |
| Peak Forward Current | 160 mA (1/10 duty cycle) |
| Operating Temperature | -40 °C to +85 °C |
The typical forward voltage is 2.0 V at 20 mA, ranging up to 2.5 V.
The peak wavelength is 627 nm.
The device operates from –40 °C up to +85 °C.
Yes, the WP483EDT is RoHS compliant.
