The AD807 is a fiber optic receiver with a quantizer and clock recovery and data retiming. It meets CCITT G.958 requirements and Bellcore TR-NWT-000253 requirements. It accepts NRZ data, no preamble required, and has a 2.0 degrees RMS output jitter. It uses phase-locked loop type clock recovery, no crystal required. Its quantizer sensitivity is 2 mV, level detect range is 2.0 mV to 30 mV, single supply operation is +5 V or -5.2 V, low power is 170 mW, 10 KH ECL/PECL compatible output, 16-lead narrow 150 mil SOIC package.
The AD807 provides receiver functions for data quantization, signal level detection, clock recovery and data retiming at 155 Mbps NRZ data. It operates from a single supply (+5 V or –5.2 V) and consumes 170 mW, making it suitable for low‑cost SONET OC‑3 or SDH STM‑1 applications.
Key features include a 2 mV quantizer sensitivity, 2.0° RMS output jitter, 180 MHz –3 dB bandwidth, and a 16‑lead narrow‑body SOIC package. The device uses a PLL with no external crystal required and offers programmable damping via an external capacitor.
| Quantizer Sensitivity | 2 mV |
|---|---|
| Output Jitter | 2.0 degrees RMS |
| Supply Voltage | +5 V or –5.2 V (single supply) |
| Power Consumption | 170 mW |
| Package | 16‑Lead Narrow 150 mil SOIC |
| Center Frequency | 155.52 MHz |
| Upper -3 dB Bandwidth | 180 MHz |
| Input Voltage Range | 2.5 V |
The AD807 quantizer has a sensitivity of 2 mV.
It operates from a single supply of either +5 V or –5.2 V.
The output jitter is specified as 2.0 degrees RMS.
The AD807 has an upper –3 dB bandwidth of 180 MHz.
