76650-0005 is a high-density FFC/FPC connector from Molex for Flat Panel Display (FPD) and other high pincount applications. The connector features a robust design with a strong latch and is easy to use.
The 76650-0005 Flex-to-Board connector kit from Molex is a surface‑mount (SMT) solution for high‑density FFC/FPC interconnections. It offers a robust latch, low profile, and flexible jumper options with a 0.50 mm pitch and current rating of 0.5 A.
The connector is used in a wide range of applications such as LCD/PDP panels, HDTV set‑top boxes, notebooks, printers, camcorders, automotive, military, and medical equipment. The datasheet includes a detailed bill of materials listing the required FFC jumpers and FPC connectors.
| Mounting Style | SMT (Surface Mount Technology) |
|---|---|
| Pitch | 0.50mm (.020") |
| Voltage Rating | 30V, 50V |
| Wire Type | Flexible Printed Circuit Cable |
It uses a 0.50 mm (.020") pitch.
