This is a specification manual for MC2002DA-SERIES
This handbook provides detailed information for the Everbouquet MC2002DA Series LCD modules. It includes general specifications, mechanical dimensions, absolute maximum ratings, and electrical and optical characteristics needed for design and integration.
Key sections include a record of revision, mechanical data (module size, character layout), electrical limits (power supply, input voltage), optical performance (viewing angle, contrast, response time), outline dimensions, and a block diagram of the module connections.
| Dot size | 0.60 mm W × 0.65 mm H |
|---|---|
| Maximum logic power supply current | 6.0 A |
The maximum power supply current for the logic is 6.0 A.
