This file is a detailed specification of MG12064E3-SERIES. It describes the product's technical features and specifications in detail
This datasheet describes the MG12064E3‑SERIES LCD module produced by Everbouquet. It includes general specifications, mechanical dimensions, absolute maximum ratings, and detailed electrical and optical characteristics.
Key specifications include a 128 × 64 dot matrix, module size of 63.2 mm × 54.0 mm × 9.5 mm, typical supply voltage of 5.0 V, and various LED backlight options. Optical data such as viewing angle, contrast ratio, and response times are also listed.
| Number of dots | 128 CH × 64 DOTS |
|---|---|
| Module size (W × H × T) | 63.2 mm × 54.0 mm × 9.5 mm (max) |
| Effective area | 54.0 mm × 36.0 mm |
| Dot size | 0.35 mm × 0.45 mm |
| Typical Vpp‑Vss supply voltage | 5.0 V (range 4.75‑5.25 V) |
| LED backlight forward voltage (yellow‑green, amber, orange, red) | 4.8 V |
| Contrast ratio | 10 |
| Operating temperature range | -20 °C to 70 °C |
The module measures 63.2 mm wide, 54.0 mm high, and up to 9.5 mm thick.
The typical Vpp‑Vss supply voltage is 5.0 V, with a permitted range of 4.75 V to 5.25 V.
Yellow‑green, amber, orange, and red LEDs use a forward voltage of 4.8 V, while white, blue, and pure‑green LEDs use 4.0 V.
The LCD can operate from –20 °C up to 70 °C.
