The P2500 is a high-precision, high-stability speed sensor with an accuracy of 0.2% and 0.01° and a frequency range of 0-10000r/min. It also has good anti-interference ability.
The P2500 series angle sensor is a compact, high‑performance potentiometer‑type sensor with a metal housing, spherical bearings, conductive plastic substrate, and elastic‑damped brush. It offers excellent linearity (≤0.2 %), high resolution (better than 0.01°), and can operate at speeds up to 10 000 rpm with unlimited continuous rotation.
The manual lists mechanical dimensions, installation using three Z1‑11 clamps, electrical parameters such as resistance values (1 kΩ, 2 kΩ, 5 kΩ), voltage range up to 42 V, and environmental limits including a temperature range of –40 °C to +100 °C and IP40 protection. Ordering information and optional accessories are also provided. This manual is written in Chinese.
| Operating temperature range | -40 °C ~ +100 °C |
|---|---|
| Static/Dynamic load capacity | 15 N |
It operates from –40 °C to +100 °C.
The sensor can handle a static or dynamic load of 15 N.
