This document describes the features and characteristics of the TX2 series products, including their waterproof rating, measurement accuracy, and electrical parameters.
The TX2 series linear displacement sensors are compact, low‑cost devices designed for harsh environments. They feature a stainless‑steel pull‑rod, anodized aluminum housing, and optional radial connectors or cables.
Electrical specifications include selectable resistance values, a maximum supply voltage of 42 V, and a repeatability of 0.01 mm. Mechanical data provide travel ranges from 25 mm to 300 mm, IP67 protection, and a rated life of over 50 million cycles. This manual is written in Chinese.
| Working range | 25‑300 mm |
|---|---|
| Electrical travel | 27‑305 mm |
| Standard resistance values | 1‑12 kΩ |
| Independent linearity | 0.05‑0.2 % |
| Repeatability | 0.01 mm |
| Maximum supply voltage | 42 V |
| IP protection rating | IP67 |
| Operating temperature range | -40 °C to +85 °C (connector) / -20 °C to +100 °C (cable) |
| Operating humidity range | 0 %‑95 % RH (non‑condensing) |
| Vibration resistance | 5‑2000 Hz |
| Shock resistance | 50 g |
| Rated life | >50 × 10⁶ cycles |
The TX2 sensor is rated IP67, meeting DIN EN 60529 standards.
The sensor can be powered with up to 42 V.
The repeatability is specified as 0.01 mm.
The sensor is offered with travel ranges from 25 mm up to 300 mm.
