DPG 60 C 300 HB is a low leakage current, low recovery time, low power Schottky diode, suitable for anti-parallel diodes, anti-saturation diodes, clamp diodes, freewheeling diodes, rectifiers in switch mode power supplies (SMPS) and uninterruptible power supplies (UPS).
The DPG 60 C 300 HB is a high‑performance fast recovery diode featuring very low leakage current, short recovery time, and soft reverse recovery for low EMI/RFI. It is suitable for high‑frequency switching devices, snubber and free‑wheeling applications, and SMPS/UPS rectifiers.
The device is supplied in a common‑cathode TO‑247 package and includes detailed electrical and thermal parameters such as a 300 V reverse voltage rating, 30 A average forward current, 35 ns reverse recovery time, and a junction‑to‑case thermal resistance of 0.95 K/W. This manual is written in Chinese.
| Maximum Repetitive Reverse Voltage (VRRM) | 300 V |
|---|---|
| Junction‑to‑Case Thermal Resistance (RthJC) | 0.95 K/W |
| RMS Reverse Current (IRMS) | 50 A per pin |
| Package Type | Common Cathode TO‑247 |
The diode is rated for a maximum repetitive reverse voltage of 300 V.
It is supplied in a common‑cathode TO‑247 package.
