DSA 70 C 150 HB is a high performance Schottky diode with very low Vf and extremely low switching losses
The DSA 70 C 150 HB is a high‑performance Schottky diode featuring very low forward voltage, low reverse recovery loss and high reliability. It is intended for use as a rectifier in switch‑mode power supplies and as a free‑wheeling diode in low‑voltage converters.
The device is supplied in a TO‑247 housing, rated for 150 V reverse voltage and 35 A continuous forward current. Key electrical parameters, thermal resistance, storage temperature range and mechanical dimensions are listed, and the part is RoHS compliant.
| Reverse voltage (VRRM) | 150 V |
|---|---|
| Package | TO‑247 |
| Thermal resistance (junction‑to‑case) | 0.70 K/W |
| Storage temperature range | -55 °C to 150 °C |
| Weight | 6 g |
| RoHS compliance | Yes |
The diode is rated for a maximum repetitive reverse voltage of 150 V.
The device is supplied in a TO‑247 housing.
Yes, the DSA70C150HB is RoHS compliant.
