The BS616LV8016 is a 512K x 16-bit low-power CMOS SRAM. It features a 2.4V ~ 5.5V wide power range, 0.8uA typical standby current, 55ns maximum access time, and an automatic power down feature.
The BS616LV8016 is a high‑performance, very low‑power CMOS static RAM organized as 524,288 × 16 bits (512 K × 16). It operates from a wide supply range of 2.4 V to 5.5 V and offers fast access times as low as 55 ns.
The device is available in DICE and 48‑ball BGA packages, supports automatic power‑down when deselected, and provides three‑state TTL‑compatible outputs. It is qualified for industrial temperature ranges (‑40 °C to +85 °C).
| Memory organization | 524,288 × 16 bits (512 K × 16) |
|---|---|
| Supply voltage | 2.4 V ~ 5.5 V |
| Maximum access time | 55 ns |
| Package types | DICE, BGA‑48‑0912 |
| Industrial temperature range | -40 °C ~ +85 °C |
It operates from 2.4 V to 5.5 V.
It is offered in DICE and 48‑ball BGA packages.
The maximum access time is 55 ns at Vcc 3.0 V–5.5 V.
