This document describes the experience gained by MENTOR in developing and supplying components for industrial electronics, as well as their LED display systems. These display systems have the advantages of infinite lifetime and low current consumption, with commonly used colors being red, yellow, and green.
The manual describes Mentor's LED display systems, highlighting the decades of experience behind their development and the variety of LED modules available as single, multi‑LED or strip forms. It outlines the standard 2.54 mm base grid and compliance with industrial electronics norms.
Technical details include LED colors (red, yellow, green), common diameters (3 mm and 5 mm), operating temperature range (‑40 °C to +85 °C), ESD robustness (15 kV per DIN IEC 801‑2), and packaging options. Ordering information and special requirements such as reverse polarity are also covered. This manual is written in German.
| Base grid pitch | 2.54 mm |
|---|---|
| LED diameter | 3 mm and 5 mm |
| Operating temperature range | -40 °C to +85 °C |
| Standard LED colors | Red, Yellow, Green |
The most frequently used colors are red, yellow, and green.
The operating temperature range is –40 °C to +85 °C.
The base grid pitch is 2.54 mm.
