This document details the features, specifications and parameters of 1273.1011, including the type of light guide system, the number of light guide plates and the length of light guide.
The 1701 series light guide strip from Philips is a single‑line, 2 × 5 mm light guide designed to be mounted on a printed circuit board with a 5.08 mm pitch. It is held in place by press‑in lugs and works together with SMD LEDs, guiding light parallel to the front panel.
The product can be supplied in 1‑fold to 10‑fold configurations, with a variable length (A) from 8.1 mm to 45 mm. Minimum order quantities are 1 000 pieces for 1‑ to 9‑fold displays, while special lengths are available on request. This manual is written in German.
| Ambient Temperature | -40 °C to +85 °C |
|---|---|
| ESD Protection | <12 kV |
| Minimum Order Quantity | 1 000 pieces for 1‑ to 9‑fold displays |
The light guide operates from –40 °C up to +85 °C.
It offers ESD protection of less than 12 kV.
The minimum order is 1 000 pieces for 1‑ to 9‑fold displays.
