MENTOR 4-fach-Anzeige liegend m. sphärischer Abstrahlfläche Ø3mm 4-fold Display lying w. Spherical Radiating Surface Ø3mm

About this manual

The document provides technical specifications for Mentor's 4‑fold display featuring a spherical radiating surface. It lists material choices for the light guide (PC clear UL94) and the diaphragm (PC black UL94), as well as environmental limits such as an ambient temperature range of -40 °C to +85 °C and ESD protection below 12 kV.

Additional details include the recommended LED part numbers (L1‑L12 1276.1004), the spacing between light guides (3.8 mm), and layout suggestions for integration on printed circuit boards. The sheet also references further general remarks and technical data on subsequent pages. This manual is written in German.

What's inside

• General Remarks and Technical Data
• LL-Material
• Diaphragm-Material
• Ambient Temperature
• ESD-Protection
• Recommended LEDs
• Light Guide Spacing
• Layout Suggestion
