This document provides various display, including single line and multi line. They are made of PC clear UL94 material with working temperature of -40°C to +85°C.
The Philips L1‑L128 multiple display light guide is a single‑line Ø3 mm light‑guide system that replaces FEL in a 5.08 mm pitch. It is mounted on the PCB via press‑in lugs and guides light parallel to the board toward the front panel. The system is used together with SMD LEDs and can be supplied in 1‑fold to 10‑fold configurations.
The length of the light guide (A) is variable from 8.1 mm to 45 mm. Minimum order quantity is 1 000 pieces for 1‑ to 9‑fold displays, with special lengths available on request. Recommended LEDs and layout suggestions are provided in the data sheet. This manual is written in German.
| Ambient temperature range | -40 °C to +85 °C |
|---|---|
| ESD protection | <12 kV |
| Length A (variable) | 8.1 mm – 45 mm |
| Minimum order quantity (1‑9 fold) | 1 000 pieces |
It operates from –40 °C up to +85 °C.
The minimum order quantity is 1 000 pieces.
