Molex Premise Networks PowerCat 6 patch cords are manufactured using high quality unshielded four pair Category 6 stranded cable. Available in a range of colours and lengths, PowerCat 6 patch cords are pre-terminated with RJ45 plugs and feature cable strain relief boots with a plug latch protection cap. Suitable for high speed data transmission, PowerCat 6 patch cords have been designed to exceed the highest electrical performance standards in the industry and have been independently tested and verified by ETL SEMKO for Category 6 component compliance.
Molex PowerCat 6 LSZH patch cords are unshielded, four‑pair Category 6 UTP cables pre‑terminated with RJ45 plugs. They are designed for high‑speed data transmission and meet industry standards such as TIA/EIA‑568‑B.2‑1, FCC Part 68, ISO 60603‑7, ISO 11801:2002, and EN 50173:2002.
The document provides detailed mechanical and electrical characteristics, including conductor size, temperature ranges, plug life, and voltage/current ratings, as well as ordering numbers for various lengths and color options.
| Conductor size | 24 AWG stranded bare copper |
|---|---|
| Maximum outer diameter | 5.6 mm |
| Cable temperature range | -20 °C to +60 °C |
| Plug operating life | Minimum 750 insertion cycles |
| Plug max voltage | 150 VAC |
| Plug max current | 1.5 A @ 25 °C |
The plug is rated for a maximum voltage of 150 VAC.
The RJ45 plug is rated for a minimum of 750 insertion cycles.
The cable can operate from –20 °C up to +60 °C.
