Cable Set models by brand
Featured Cable Set manuals
B&B Electronics CBL00600 Communications Cable Product Leaflet
The CBL00600 is a communications cable designed to link a Vlinx Fieldbus Gateway to a Keyence Koyo Model 2xx using an RS-232 interface. The cable features RJ12 connectors on the gateway side and provides the necessary pin mapping for RS-232 signals.
The cable is 10 ft (3.05 m) long and is supplied by B&B Electronics, with contact information for both the International and European headquarters included in the document.
Covers: Product Information · Connections · Physical Specifications · Manufacturer Information
Weidmüller PAC-CMLX-SD15-V3-1M5 PAC Cable Data Sheet
The PAC-CMLX-SD15-V3-1M5 is a pre‑assembled PAC cable that provides the electrical and logical connection between a PLC and its interfaces. It features a shielded LIYY or LY YCY cable with a 0.25 mm² cross‑section, a SUB‑D female 15‑pole interface connector and a ROCKWELL COMPACT LOGIX PLC connector.
Key specifications include a 1.5 m cable length, rated voltage up to 60 Vdc/25 Vac, permissible current of 1 A per path (3 A total), operating temperature from –10 °C to +50 °C, and compliance with RoHS. The cable is tested for continuity and isolation and carries the necessary eClass approvals.
Covers: General ordering data · Dimensions and weights · General Data · Cable · Electrical Data · Approvals
PRS15-3x* 15kV Equal Level Heat shrinkable three-core cable split-phase accessories installation manual
This manual describes the A600-RS heat‑shrink three‑core cable split‑phase accessory, which is suitable for electrical equipment installations handling power cables up to 15 kV and insulation diameters of 16–35 mm. It provides step‑by‑step guidance for preparing the cable, grounding the shield, applying fill and sealants, and installing the heat‑shrink components.
The procedure includes four main steps: cable pre‑treatment, shield grounding, wrapping with filling and sealing compounds, and installing the heat‑shrink three‑pin sleeve and protective tube. A material list with required parts and quantities is also provided. This manual is written in Chinese.
Covers: Product Introduction · Step 1: Cable Pre‑treatment · Step 2: Shield Grounding · Step 3: Fill and Seal · Step 4: Heat‑shrink Installation · Materials List
Pro-Signal PS110 Series Patch Lead Product Leaflet
The PS110 Series patch leads from Pro‑Signal are CAT‑5E cable assemblies designed for networking and data transmission. They feature a gold‑plated 8P8C plug and a PVC‑jacketed cable with a nominal outer diameter of 95.5 ± 0.2 mm.
The document lists part numbers for each color and length combination, covering colors such as White, Blue, Green, Grey, Red, Yellow, Pink, Violet, and Black, with lengths ranging from 0.5 m to 20 m. Detailed tables provide the exact part numbers for quick ordering.
Covers: Revisions · Specifications Table · Part Number Table
Latest Cable Set manuals
B&B Electronics CBL00600 Communications Cable Product Leaflet
Product Leaflet 1 pages · 161 KB · ENProduct information and specifications for the B&B Electronics CBL00600 communications cable that connects a Vlinx Fieldbus Gateway to a Keyence Koyo Model…
Weidmüller PAC-CMLX-SD15-V3-1M5 PAC Cable Data Sheet
Datasheet 2 pages · 59 KB · ENTechnical specifications for the Weidmüller PAC-CMLX-SD15-V3-1M5 pre‑assembled PAC cable, including dimensions, electrical data and approvals.
PRS15-3x* 15kV Equal Level Heat shrinkable three-core cable split-phase accessories installation manual
Installation Guide 2 pages · 115 KB · ZHInstallation manual for the A600-RS heat‑shrink three‑core cable split‑phase accessory, covering cable preparation, grounding, sealing and heat‑shrink steps.
Pro-Signal PS110 Series Patch Lead Product Leaflet
Product Leaflet 6 pages · 155 KB · ENThis leaflet provides part numbers, color options, lengths, and specifications for Pro‑Signal PS110 Series CAT‑5E patch leads.
Molex PowerCat 6 UTP Cable Product Leaflet
Product Leaflet 2 pages · 110 KB · ZHThe Molex PowerCat 6 UTP cable product leaflet provides key features, technical specifications, and ordering information for the 4‑pair, CMR‑rated cable.
Okonite Aerial Signal Cables Product Data Sheet
Datasheet 3 pages · 118 KB · ENTechnical data for Okonite aerial signal cables, covering construction, insulation, jacket, applications and specifications.
Okonite Okozel Case Wire Product Data Sheet
Product Leaflet 2 pages · 102 KB · ENThe Okonite Okozel Case Wire data sheet provides key specifications, ratings, and ordering details for the 600 V ETFE insulated wire.
Extron Cable Cubby 200 Junction Box Manual
User Manual 1 pages · 825 KB · ZHThe Extron Cable Cubby 200 Junction Box Manual provides an overview, features, specifications, and installation guidance for the surface‑mount cable and AC…
Belden 1592A Category 5e Patch Cable Datasheet
Datasheet 4 pages · 104 KB · ENThe Belden 1592A Category 5e patch cable datasheet provides specifications, compliance information, and physical and electrical characteristics.
Belden 1592A Category 5e Nonbonded-Pair Patch Cable Datasheet
Datasheet 4 pages · 104 KB · ENThe Belden 1592A Category 5e non‑bonded‑pair patch cable datasheet provides specifications, compliance information, and physical characteristics.
Belden 1585LC Category 5e Nonbonded-Pair Cable Product Leaflet
Product Leaflet 4 pages · 102 KB · ENThe Belden 1585LC is a 24 AWG solid bare copper Category 5e non‑bonded‑pair cable with FEP insulation, suitable for Ethernet and video applications.
Philips SWV2513 S-Video Cable Product Leaflet
Product Leaflet 2 pages · 369 KB · ZHThis Philips SWV2513 S-Video cable leaflet provides specifications, dimensions, packaging details, and safety information.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Cable Set manuals
What devices does the CBL00600 cable connect?
It connects a Vlinx Fieldbus Gateway to a Keyence Koyo Model 2xx using an RS-232 interface.
From: B&B Electronics CBL00600 Communications Cable Product Leaflet
What is the length of the CBL00600 communications cable?
The cable is 10 ft (3.05 m) long.
From: B&B Electronics CBL00600 Communications Cable Product Leaflet
What is the length of the PAC-CMLX‑SD15‑V3‑1M5 cable?
The cable is 1.5 m long.
What connectors are used on the PAC-CMLX‑SD15‑V3‑1M5?
The PLC side uses a ROCKWELL COMPACT LOGIX 1769‑RTBN 18‑pin connector, and the interface side uses a SUB‑D female 15‑pin connector.
How many layers of sealing glue are applied during installation?
Two layers of sealing glue are wrapped around the cable, with the grounding wire placed between the layers.
What is the part number for a 5 m red patch lead?
The part number for a 5 m red patch lead is PS11045.
