The SPA15N60CFD is a power transistor produced by STMicroelectronics. It has an intrinsic fast-recovery body diode, extremely low reverse recovery charge, ultra low gate charge, extreme dv/dt rating, high peak current capability, and has been qualified according to JEDEC1) for target applications. It is designed for softswitching PWM stages and LCD and CRT TVs.
The SPA15N60CFD is a CoolMOS power transistor in a PG‑TO‑220FP package, designed for soft‑switching PWM stages and high‑performance TV applications. It features an intrinsic fast‑recovery body diode, ultra‑low gate charge, and high peak current capability.
The datasheet lists key electrical parameters such as a continuous drain current of 13.4 A at 25 °C, a pulsed drain current of 33 A, and a total gate charge of 63‑84 nC. Thermal data include a junction‑to‑case resistance of 3.7 K·W⁻¹ and a maximum power dissipation of 34 W at 25 °C. Mechanical dimensions and package outlines are also provided.
| Continuous drain current (Id) at 25 °C | 13.4 A |
|---|---|
| Pulsed drain current (Iop) at 25 °C | 33 A |
| Maximum power dissipation at 25 °C | 34 W |
| Input capacitance (Ciss) | 1820 pF |
| Output capacitance (Coss) at Vps=25 V | 520 pF |
| Reverse recovery time (trr) | 147 ns |
| Gate charge total (Qg) | 63‑84 nC |
| Package type | PG‑TO‑220FP |
The maximum continuous drain current is 13.4 A at 25 °C.
The total gate charge ranges from 63 to 84 nC.
The device is supplied in a PG‑TO‑220FP package.
The transistor can dissipate up to 34 W at 25 °C.
