ATV61 is a frequency converter that can be used for synchronous and asynchronous motors. This programming manual covers the installation steps, factory settings, and parameter access examples for software version V1.8.3.
This programming manual covers all aspects needed to configure and maintain the ATV61 inverter, including safety precautions, software upgrade procedures, and detailed parameter programming. It is intended for qualified personnel who install, commission, or service the drive.
Key sections include software upgrade, installation steps, factory default settings, parameter programming examples, motor control configuration, I/O setup, fault management, communication options, and maintenance guidelines. The document also provides quick navigation aids and a comprehensive index of functions and parameters. This manual is written in Chinese.
| Default motor frequency | 50 Hz |
|---|---|
| High speed setting | 50 Hz |
| Switching frequency | 2.5 kHz or 12 kHz (depends on rating) |
| Analog input AI1 range | 0‑10 V |
| Analog output AO1 range | 0‑20 mA |
| Logical input LI1 function | Forward (1 running direction) |
Select the "Factory Settings" (FCS-) menu as described on page 217 to restore all parameters to their default values.
