This document introduces Schneider Electric's ATV71 inverter, including its compatibility with synchronous and asynchronous motors, installation steps, and the rated values of the inverter. The document also mentions Schneider Electric's development in China and its impact on the Chinese market.
The Schneider Electric ATV71 Frequency Converter Installation Guide provides comprehensive instructions for safely installing and configuring both synchronous and asynchronous motor drives. It covers important safety information, pre‑installation checks, and step‑by‑step installation procedures.
Key sections include rated values, dimensions and weight, mounting options, graphic display terminal setup, LED positioning, EMC board installation, wiring recommendations for power, control and optional terminals, wiring diagrams, and guidance for integration with IT and grounding systems. This manual is written in Chinese.
