YASKAWA III Series SGM/SGDS Servo Unit User Manual

This manual introduces the overview, selection, specifications, wiring, communication, operation, adjustment, maintenance and inspection of servo unit SGDS-���12A and related products.

YASKAWA III Series SGM/SGDS Servo Unit User Manual - cover page
Brand
Σ-III
Category
Servo motor
Document type
User Manual
Language
Chinese
Pages
357
File format
PDF
File size
23.1 MB
Published
16 March, 2012
Updated
30 September, 2023
MD5 checksum
EF32D98CE7C4CC4EB41286B873E41344
PDF
YASKAWA III Series SGM/SGDS Servo Unit User Manual PDF

About this manual

The manual covers all aspects of the III series SGM/SGDS servo units, including safety precautions, product specifications, wiring requirements, and MECHATROLINK‑II communication configuration. It also provides detailed procedures for operation, adjustment, enclosed‑control handling, and routine maintenance.

Additional sections describe recommended installation environments, cable routing rules, power‑voltage limits, and troubleshooting tips, ensuring safe and reliable integration of the servo units into automation systems. This manual is written in Chinese.

What's inside

  • Overview
  • Selection
  • Specifications and Dimensions
  • Cable and Peripheral Specifications
  • Wiring
  • MECHATROLINK‑II Communication
  • Operation
  • Adjustment
  • Enclosed Control
  • Maintenance and Inspection

Specifications

Supported servo motor modelsSGMMJ, SGMAS, SGMPS, SGMSS, SGMCS, SGMGH
Maximum feedback line length20 m

Frequently asked questions

What safety precautions should be taken after power is turned off?

Wait at least five minutes before touching any terminals, because residual voltage may still be present.

Can a 100 V or 200 V servo unit be connected to a 400 V power source?

No. A 100 V or 200 V servo unit must not be directly connected to a 400 V supply.

Download PDF (23.1 MB)
