This document introduces a MOS FET electronic device with low resistance, high voltage, and high current characteristics. The device is suitable for AC/DC applications, with surface mount terminals and RoHS certification.
The G3VM‑61HR is an optocoupler‑type MOS‑FET relay designed for AC/DC conversion and LED‑driver applications. The datasheet provides detailed electrical parameters, performance curves, and usage conditions.
Key information includes on‑state resistance, off‑state resistance, voltage and current ratings, and recommended operating temperature ranges. The document also contains typical characteristic graphs and safety notes for reliable operation. This manual is written in Chinese.
| Maximum On‑Resistance (RON) | 0.02 Ω |
|---|---|
| Maximum Supply Voltage (VDD) | 20 V |
The on‑state resistance (RON) is specified as 0.02 Ω.
The relay is rated for a maximum supply voltage of 20 V (VDD).
