This is the PDF datasheet of OMRON G3VM-61G2, which details the features and characteristics of the product.
The G3VM-61G2 is an ultra‑sensitive MOS FET relay from Omron, designed for low power consumption and long battery life. It features a compact surface‑mount package and LED indicators for status monitoring.
The datasheet lists key electrical characteristics such as a maximum load voltage of 60 V, continuous load current of 400 mA, LED forward current of 1 mA (max), and an input‑output isolation voltage of 1500 V. It also specifies an operating temperature range from –55 °C to +125 °C and provides recommended action and release conditions for reliable operation. This manual is written in Chinese.
| Maximum load voltage | 60 V |
|---|---|
| Continuous load current | 400 mA |
| LED forward current (max) | 1 mA |
| Input‑output isolation voltage | 1500 V |
| Operating temperature range | -55 °C to +125 °C |
| LED forward voltage | 1.3 V |
The relay can handle a maximum load voltage of 60 V.
The continuous load current rating is 400 mA.
It operates from –55 °C to +125 °C.
The isolation voltage between input and output is 1500 V.
