CoolRunner™ XPLA3 XCR3384XL is a low-power CPLD product with 384 macrocells and a maximum system frequency of 135MHz. It features small footprint, low power consumption, and advanced system functions.
The XCR3384XL is a 384‑macrocell CPLD optimized for 3.3 V low‑power operation. It offers up to 135 MHz maximum system frequency, 7 ns pin‑to‑pin logic delay, and advanced features such as in‑system programming, JTAG boundary‑scan, and configurable I/O.
The document lists detailed DC and AC electrical characteristics, internal timing parameters, switch characteristics, and pin‑out tables for multiple package options (TQ144, PQ208, FT256, FG324, etc.). Package markings and ordering information are also provided. This manual is written in Japanese.
| Maximum system frequency | 135 MHz |
|---|---|
| Pin‑to‑pin logic delay | 7.0 ns |
| Standby current (25 °C) | 18 µA |
| Number of macro cells | 384 |
The device can operate up to 135 MHz.
It contains 384 macro cells.
The standby current is 18 µA at 25 °C.
