This manual introduces the product features, specifications, dimensions, quality grades of PG1-SAS series pressure gauges.
The document describes the PG1 series pressure gauges (e.g., PG1‑SAS, PG1‑SAS‑ADJ, PG1‑DIM, PG1‑SFB) offered by Bosch Rexroth. It lists the series names, connection types, color coding, measurement units (bar/psi) and ATEX certification (II 2G2D T4 X).\n\nTechnical tables give detailed dimensions, pressure ranges, material options, and temperature limits for each model variant. Contact information for Bosch Rexroth offices in China and Germany is also included. This manual is written in Japanese.
| Measurement unit | bar / psi |
|---|---|
| ATEX certification | II 2G2D T4 X |
| Operating temperature range | -40 °C to +60 °C |
| Series example | PG1‑SAS |
The gauges measure pressure in both bar and psi.
Yes, they are certified to ATEX II 2G2D T4 X.
The gauges operate from –40 °C to +60 °C.
