Bosch Rexroth PG1 Pressure Gauge User Guide
This guide covers the Bosch Rexroth PG1 series pressure gauges, including the PG1‑SAS, PG1‑DIM and PG1‑SFB variants. It provides technical data such as pressure ranges, temperature limits, material construction, and ATEX classification, together with mounting dimensions and connection options.
The document also lists contact information for Bosch Rexroth offices in China and Germany, and includes legal notices about the proprietary nature of the data. It is intended for users who need to install, operate, or maintain these pressure gauges in industrial applications. This manual is written in Japanese.
Rexroth PG1 specifications
| Measurement unit | bar / psi |
|---|---|
| ATEX certification | II 2G2D T4 X |
| Operating temperature range | -40 °C to +60 °C |
| Series example | PG1‑SAS |
All Rexroth PG1 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What measurement units are used for the PG1 series pressure gauges?
The gauges measure pressure in both bar and psi.
Are the PG1 series pressure gauges ATEX certified?
Yes, they are certified to ATEX II 2G2D T4 X.
What is the pressure range of the PG1‑SAS gauge?
The PG1‑SAS gauge measures pressures from 0 to 12 bar.
What ATEX classification does the PG1 series have?
The gauges are certified to ATEX II 2G2D T4 X.
