This document is the product manual for the supplementary products of Bosch Rexroth AG's pneumatic connection technology NU2 series. The manual introduces the different types of pneumatic connectors in the NU2 series, including direct heads, angle rotation connectors, straight tube connectors with caps, T-connectors, X-connectors, adjacent connectors, partition tube connectors, elbows, 1-grid circular support pieces, 2-grid circular support pieces, T-connectors, and T-rotating connectors. These connectors have different thread specifications and connection diameters, suitable for various pneumatic connection needs.
This user guide describes the various connection options for the Bosch Rexroth NU2 series pneumatic components. It lists part numbers such as NU2‑S‑RPN, NU2‑S‑RW1, and provides details on dimensions, thread types, and recommended installation practices.
Technical limits are given, including operating temperature from –10 °C to +60 °C and working pressure from –0.95 bar to 10 bar. Material specifications, weight data, and contact information for Bosch Rexroth offices worldwide are also included. This manual is written in Japanese.
