ED07 series electric proportioning valve, an adjustable pilot valve lifting type solenoid valve, can be applied to pneumatic system for gas flow regulation.
This guide describes the ED07 pressure regulate valve series, its intended applications, and safety information. It includes wiring diagrams, pressure settings, and mechanical dimensions needed for proper installation.
Technical data such as pressure range, electrical supply, temperature limits, and environmental protection rating are listed, along with handling instructions and contact details for Bosch Rexroth support.
| Maximum pressure | 1300 min |
|---|---|
| Operating temperature | 45°C / +50°C |
| Maximum current | 14 A |
| Weight | 2.05 kg |
The valve is rated for a maximum pressure of 1300 min.
The valve can operate between 45°C and +50°C.
