Sony SSC-DC490 Series Camcorder User Manual
The Sony SSC-DC490 series camcorder is a high‑definition color video camera that uses Sony's Super HAD CCD sensor and advanced DSP technology to deliver detailed images. It includes functions such as back‑light compensation, auto white balance (ATW), CCD iris control, and Turbo AGC, making it suitable for professional, educational, and medical environments.
The manual provides technical specifications, installation instructions, and a list of supplied accessories. It details power requirements, operating temperature ranges, and key performance parameters such as resolution, pixel count, and minimum illumination levels. This manual is written in Japanese.
SONY SSC-DC490 specifications
| Imaging sensor | 173 英寸 Supe HAD COD |
|---|---|
| Pixels (horizontal x vertical) | 752 x 582 |
| Sensitivity | 4 8X3.6nm |
| Signal format | AL |
| Horizontal resolution | 540 |
| Minimum illumination | 0.45 lx at F1.3 |
| Power supply | DC12V or AC24V, 220W AC |
| Power consumption | 3.5 W |
| Weight | 360 g / 385 g |
| Dimensions (W×H×D) | 60 x 54 x 120 mm |
| Operating temperature | -10°C to 50°C |
| Storage temperature | -40°C to 60°C |
All SONY SSC-DC490 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What type of image sensor does the SSC-DC490 series camcorder use?
It uses a Super HAD CCD sensor.
What are the power requirements for the camcorder?
The camcorder can be powered by DC12V or AC24V (220 W AC) and consumes about 3.5 W.
