Key facts
- Brand
- Rigol
- Model
- M300
- Category
- Industrial Supply
- Industry
- Industrial
- Documents
- 8
- Languages
- ZH · EN
- Last added
- 2026-10-17
Start here
RIGOL M300 Data Acquisition Switch System Quick Guide
The RIGOL M300 Quick Guide introduces the front and rear panels, user interface, and basic measurement functions of the data acquisition/switch system. It includes safety requirements, handling, cleaning, and environmental considerations to help users become familiar with the instrument quickly.
The guide also provides step‑by‑step instructions for basic operations such as connecting measurement signals, configuring scan lists, remote control, and troubleshooting common issues like power‑up problems, interface failures, and lockouts. This manual is written in Chinese.
RIGOL M300 specifications
| Communication Interfaces | USB, LAN, RS232, GPIB |
|---|---|
| Software Version | 00.02.00 .04.19 |
| Document Number | PGC0700 4-1110 |
Source: RIGOL M300 Data Acquisition/Switching System Programming Manual
All RIGOL M300 documents by type
Instruction set, parameters and examples for configuring or programming the device.
The shortest path to a working setup, usually only a few pages.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How can I establish remote communication with the M300?
You can establish communication via USB, LAN, RS232, or GPIB (IEEE-488) interfaces.
From: RIGOL M300 Data Acquisition/Switching System Programming Manual
What software is required for PC control?
The Ultra Sigma general-purpose PC software is required for installation and control.
From: RIGOL M300 Data Acquisition/Switching System Programming Manual
How can I change the system language?
Press Utility → System, select Language, and choose the desired language using the up/down direction keys.
How do I replace the power fuse?
Turn off the instrument and unplug the power cord. Use a flat‑head screwdriver to open the fuse cover, remove the old fuse, and install a new fuse with the specified rating (AC 250 V T3.15 A). Reinstall the cover and restore power.
How many switching channels does the M300 support?
The M300 can support up to 320 switching channels.
What fuse specification is required for the DMM module?
A fuse rated AC 250 V, T 250 mA is required.
