RIGOL DP800 Series Manuals

ManualLib has 6 documents for the RIGOL DP800 Series (Power Management): 4 user manuals, 2 quick start guides. Every file can be read online or downloaded as a PDF for free.

User Manual 4Quick Start Guide 2

Key facts

Brand
Rigol
Model
DP800 Series
Industry
Electronics
Documents
6
Languages
EN · ZH
Last added
2026-11-01

Start here

RIGOL DP800 Series Programmable Linear DC Power Supply Quick Start Guide

RIGOL DP800 Series Programmable Linear DC Power Supply Quick Start Guide

Quick Start Guide 59 pages · 1.3 MB · ZH

This document serves as a quick start guide for the RIGOL DP800 series of programmable linear DC power supplies. It provides essential information on safety requirements, maintenance and cleaning instructions, an overview of the documentation format, and basic operational procedures to help users get started quickly.

The guide details how to perform initial checks, connect power correctly (including voltage selector settings and fuse replacement), operate the front panel user interface in various display modes, and handle common faults. It also includes specific technical data for different models within the series regarding output channels and ratings. This manual is written in Chinese.

Read online

RIGOL DP800 Series specifications

Display3.5-inch TFT
Total Output Power200W
Communication InterfacesUSB HOST, USB DEVICE, LAN, RS232, Digital I/O
Remote Control StandardSCPI
Instrument StandardLXI Core 2011

Source: RIGOL DP800 Series Programmable Linear DC Power Supply User Manual

All RIGOL DP800 Series documents by type

Quick Start Guide 2

The shortest path to a working setup, usually only a few pages.

Questions answered in these manuals

Can I use any power cord with the DP800?

Only use the exclusive power cord designed for the instrument and authorized for use within the local country.

From: RIGOL DP800 Series Programmable Linear DC Power Supply User Guide

What is the maximum operating temperature for the DP800 Series power supply?

The manual does not state a specific maximum operating temperature, but it warns that inadequate ventilation may cause an increase of temperature in the instrument.

From: RIGOL DP800 Series Programmable Linear DC Power Supply User Guide

Can the DP800 series be used for current sourcing?

No, it should only be used to power loads that do not have current output functions to prevent control loop instability.

From: RIGOL DP800 Series Programmable Linear DC Power Supply User Manual

What happens if the self-test fails upon startup?

The system will display a corresponding self-test failure message, including details about the analog board, fan, or temperature.

From: RIGOL DP800 Series Programmable Linear DC Power Supply User Manual

What are the fuse specifications for DP832 models?

For input voltages of 100Vac or 115Vac, use a T6.3A fuse; for 230Vac, use a T3.15A fuse.

From: RIGOL DP800 Series Programmable Linear DC Power Supply Quick Start Guide

What happens if the self-check fails after startup?

If the self-check fails, the system will display a corresponding failure message indicating issues with the analog board, fan, or temperature.

From: RIGOL DP800 Series Programmable Linear DC Power Supply Quick Start Guide
