RIGOL DS1000CA Series Manuals

ManualLib has 6 documents for the RIGOL DS1000CA Series (Oscillator): 3 datasheets, 1 user manual. Every file can be read online or downloaded as a PDF for free.

Datasheet 3User Manual 1

Key facts

Brand
Rigol
Model
DS1000CA Series
Category
Oscillator
Industry
Electronics
Documents
6
Languages
ZH · EN
Last added
2026-10-16

Start here

RIGOL DS1000CA Series Digital Oscilloscope User's Guide

RIGOL DS1000CA Series Digital Oscilloscope User's Guide

User Manual 154 pages · 1.7 MB · EN

The RIGOL DS1000CA Series Digital Oscilloscopes User's Guide provides operating instructions for the DS1302CA, DS1202CA, DS1102CA, and DS1062CA models. It includes safety notices, getting started steps, and general oscilloscope operation.

Key features include dual-channel operation, bandwidths from 60MHz to 300MHz, a color TFT LCD with 320 × 234 pixel resolution, USB storage and printing, 20 automatic measurements, built-in FFT, and digital filters.

Read online

RIGOL DS1000CA Series specifications

Bandwidth (DS1302CA)300MHz
Real-time Sampling Rate2GSa/s
Waveform Capture Rate2000wfms /s
Display Type145mm (5.7 inch) TFT LCD
Input Impedance1MΩ±2% // 15pF±3pF
Max Input Voltage (DC+AC Peak)300V (10X probe)
Power Supply100-240 VAC RMS, 45-66Hz
Operating Temperature Range10°C to +40°C

Source: RIGOL DS1000CA Series Digital Oscilloscope Data Sheet

All RIGOL DS1000CA Series documents by type

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

Does the oscilloscope support FFT?

Yes, the DS1000CA series includes embedded FFT functionality along with practical digital filters.

From: RIGOL DS1000CA Series Digital Oscilloscope Data Sheet

What is the maximum input voltage for the oscilloscope?

The maximum input voltage is 300V when using a 1MΩ input impedance and 10X probe attenuation.

From: RIGOL DS1000CA Series Digital Oscilloscope Data Sheet

What are the models included in the DS1000CA series?

The series includes the DS1302CA, DS1202CA, DS1102CA, and DS1062CA models.

From: RIGOL DS1000CA Series Digital Oscilloscope Datasheet

What is the maximum real-time sampling rate?

The maximum real-time sampling rate is 2GSa/s.

From: RIGOL DS1000CA Series Digital Oscilloscope Datasheet

What trigger types does the DS1000CA series support?

It supports edge, pulse‑width, slope, video, and alternate trigger modes.

From: Rigol DS1000CA Series Digital Oscilloscope Datasheet

How many automatic measurement parameters are available?

The oscilloscope provides 20 automatic measurement parameters.

From: Rigol DS1000CA Series Digital Oscilloscope Datasheet
