Start here
Analog Devices High Speed High Accuracy 14-Bit 16-Bit 18-Bit PulSAR ADCs Product Leaflet
Analog Devices presents its industry-leading portfolio of 14-bit, 16-bit, and 18-bit SAR ADCs, designed to provide uncompromised speed, accuracy, and low power consumption. The document highlights specific models like the AD7621 (16-bit, 3 MSPS) and the AD7641 (18-bit, 2 MSPS), emphasizing their suitability for applications in medical imaging, communications, and data acquisition.
Read onlineAnalog Devices AD7674 specifications
| Resolution (AD7621) | 16-bit |
|---|---|
| Throughput (AD7621) | 3 MSPS |
| Resolution (AD7641) | 18-bit |
| Throughput (AD7641) | 2 MSPS |
| Supply Voltage | 2.5 V |
| Package Options | 48-lead LQFP, 48-lead LFCSP |
Source: Analog Devices High Speed High Accuracy 14-Bit 16-Bit 18-Bit PulSAR ADCs Product Leaflet
All Analog Devices AD7674 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the fastest 16-bit SAR ADC in the portfolio?
The AD7621 is the fastest 16-bit SAR ADC, providing a 3 MSPS sampling rate.
From: Analog Devices High Speed High Accuracy 14-Bit 16-Bit 18-Bit PulSAR ADCs Product Leaflet
What is the highest resolution and speed offered?
The highest resolution is 18 bits at 2 MSPS, provided by the AD7641.
From: Analog Devices High Speed High Accuracy 14-Bit 16-Bit 18-Bit PulSAR ADCs Product Leaflet
What is the maximum integral nonlinearity (INL) of the AD7674?
The AD7674 has a maximum INL of +2.5 LSB (±9.5 ppm of full scale).
What are the available package options for the AD7674?
It is offered in 48‑lead LQFP and 48‑lead LFCSP packages.
What is the maximum conversion rate in Warp mode?
The AD7674 can achieve up to 800 kSPS in Warp mode.
From: ANALOG DEVICES 18-Bit 2.5 LSB INL 800 kSPS SAR ADC Manual
How much power does the AD7674 consume at 800 kSPS?
Typical power dissipation is 98 mW at 800 kSPS.
From: ANALOG DEVICES 18-Bit 2.5 LSB INL 800 kSPS SAR ADC Manual
