This Molex product specification details the performance, electrical, mechanical and packaging requirements for the PicoBlade 1.25 mm SMT vertical connector…
The document provides the full product specification for Molex's PicoBlade 1.25 mm SMT vertical type connector equipped with a vacuum cap. It defines the part numbers, packaging quantities, and the applicable wire sizes for the series.
Key technical data include a maximum rated voltage of 125 V, rated currents up to 1 A for AWG #26‑#28, contact resistance of 20 mΩ max, insulation resistance of 100 MΩ min, and a dielectric strength of 250 V AC for one minute. Mechanical requirements such as insertion force (4.9 N max) and crimp pull‑out forces are also listed, together with recommended storage conditions and handling guidelines. This manual is written in Japanese.
| Maximum Rated Voltage | 125 V (rms) |
|---|---|
| Rated Current (AWG #26) | 1.0 A |
| Rated Current (AWG #28) | 1.0 A |
| Ambient Temperature Range | -40 °C ~ +105 °C |
| Storage Temperature Range | -5 °C ~ +35 °C |
| Maximum Contact Resistance | 20 mΩ |
| Minimum Insulation Resistance | 100 MΩ |
| Insertion Force | 4.9 N max |
| Crimp Pull‑out Force (AWG #26) | 19.6 N min |
The connector is rated for a maximum voltage of 125 V (rms).
Contact resistance must be 20 mΩ maximum when tested with a 10 mA current.
Store the part at -5 °C to +35 °C with humidity up to 70 % RH and use it within 48 hours.
The insertion force is limited to 4.9 N maximum.
