Aonda 865PEN/865PN/P5PE-X mainboard adopts Intel 82865PE and 82801EB chipsets, provides users with an integrated, compatible, high-value ATX system platform with stable performance and reasonable price, which is suitable for high-end business and home entertainment.
This manual introduces the ONDA 865PEN/865PN/P5PE-X ATX motherboard, detailing its Intel 82865PE/82801EB chipset, supported CPUs, memory options, and expansion slots. It also covers safety precautions, required tools, and the proper handling of sensitive components.
Step‑by‑step instructions guide users through CPU and memory installation, jumper settings, and connecting peripherals such as USB, LAN, and audio devices. BIOS configuration and audio system setup are explained, allowing users to customize system performance and sound output. This manual is written in Chinese.
| Chipset | Intel 82865PE and 82801EB |
|---|---|
| CPU Socket | Socket‑478 |
| Supported CPUs | Intel Pentium 4, Celeron 4 (400/533/800 MHz FSB) |
| Maximum Memory Bandwidth | 6.4 GB/s |
| AGP Slot | 1 × AGP 8X (supports 4X/8X) |
| USB Ports | 8 × USB 2.0 |
| LAN | Optional 10/100 Mbps RJ‑45 |
| Audio | AC97 v2.2, 6‑channel |
It uses a Socket‑478 processor socket.
The motherboard includes eight USB 2.0 ports.
The audio subsystem follows the AC97 v2.2 specification.
