The SC116009/SC116008 series are 8‑bit HCS08 microcontrollers featuring a 40 MHz CPU core and a 20 MHz internal bus. They provide up to approximately 60 KB of flash memory and 2 KB of on‑chip RAM, with support for up to 32 interrupt sources.
The devices include a rich set of peripherals such as up to 16‑channel 8‑bit ADCs, up to 54 general‑purpose I/O pins, multiple serial interfaces (SCI, LIN, SPI), and flexible timer/PWM modules. They are offered in 64‑pin and 44‑pin LQFP packages. This manual is written in Chinese.
| CPU speed | 40 MHz |
|---|---|
| Internal bus speed | 20 MHz |
| Flash memory | ≈60 KB |
| RAM | 2 KB |
| Interrupt sources | Up to 32 |
| ADC channels | Up to 16 channels, 8‑bit |
| General‑purpose I/O pins | Up to 54 |
| Package options | 64‑pin LQFP, 44‑pin LQFP |
The devices provide up to about 60 KB of flash memory.
Up to 54 general‑purpose I/O pins are supported.
The microcontroller runs at a 40 MHz HCS08 CPU.
The series is offered in 64‑pin and 44‑pin LQFP packages.
