This document describes the features and characteristics of the Zynq UltraScale+ development platform ACU2CG core board, including the chip, DDR4 DRAM, QSPI Flash, eMMC Flash, clock configuration, LED lights, power supply, etc.
The document introduces the Alinx ACU2CG core board, which is built around the Xilinx Zynq UltraScale+ MPSoC XCZU2CG-1SFVC784E chip. The PS subsystem features dual ARM Cortex-A53 processors running at 1.2GHz and two Cortex-R5 cores at 500MHz. It integrates 2GB of DDR4 SDRAM, a 256MBit QSPI Flash, and an 8GB eMMC Flash for storage. This manual is written in Chinese.
| Processor (PS) | 2x ARM Cortex-A53 @ 1.2GHz, 2x Cortex-R5 @ 500MHz |
|---|---|
| Memory Capacity | 2GB DDR4 SDRAM |
| DDR4 Speed | 1200MHz (2400Mbps) |
| QSPI Flash Size | 256MBit |
| eMMC Flash Size | 8GB |
| Board Dimensions | 80*60mm |
