User manual for the Alinx AXP100 high-end FPGA development platform based on the Logos-2 series PG2L100H chip, covering core board, expansion board, and…
This manual describes the Alinx AXP100, a high-end FPGA development platform based on the Ziguang Tongchuang Logos-2 series PG2L100H chip. The platform utilizes a core board and expansion board architecture to facilitate secondary development. The core board features the PG2L100H FPGA, two DDR3 memory chips, and a QSPI Flash, providing high-speed data processing and storage capabilities with a bandwidth up to 25Gb/s.
The expansion board provides a variety of interfaces including PCIe x2, dual SFP fiber optic interfaces, HDMI input and output, Gigabit Ethernet, USB-UART, SD card slot, and various GPIO expansion ports. The document details the hardware structure, pin assignments for buttons and LEDs, power supply design, and specific parameters for the FPGA and peripheral components. This manual is written in Chinese.
| FPGA Model | PG2L100H-6IFBG676 |
|---|---|
| FPGA Package | FBG676 |
| System Bandwidth | 25Gb/s |
| DDR3 Capacity | 8Gbit |
| PCIe Interface | PCIe x2 |
| Fiber Optic Interfaces | 2 SFP |
| HDMI Output | 1080P@60Hz |
| HDMI Input | 1080P@60Hz |
| Ethernet Interface | 10/100/1000 Mbps |
| Power Input | DC12V |
| Core Board Size | 60*60 mm |
The AXP100 uses the Ziguang Tongchuang Logos-2 series PG2L100H chip.
The entire system bandwidth reaches 25Gb/s.
The power input voltage for the board is DC12V.
Yes, it supports one HDMI output and one HDMI input interface.
