This manual covers the features, components, and configuration of the Alinx AX7021 ZYNQ FPGA Development Board based on the Xilinx XC7Z020 chip.
The Alinx AX7021 is a ZYNQ FPGA development board based on the Xilinx Zynq7000 series chip, model XC7Z020-2CLG484I. The board features a Processing System (PS) with two ARM Cortex-A9 processors and a Programmable Logic (PL) with 85K logic cells. It includes two SK Hynix DDR3 chips for a total of 8GB capacity and supports high-bandwidth data processing up to 533MHz.
| DDR3 Frequency | 533MHz |
|---|---|
| Logic Cells | 85K |
| BlockRAM | 4.9Mb |
| Board Size | 2.36 inch * 2.36 inch |
Yes, the PS system includes an Ethernet interface as a peripheral.
The AC7021 core board is an FPGA development board based on the Zynq chip XC7Z020-2CLG484l of the XILINX ZYNQ7000 series.
The core board size is only 2.36 inch* 2.36 inch.
