The manual details the ACU5EV core board based on Xilinx Zynq UltraScale+ MPSoC, covering hardware components, interfaces, and configuration.
The ACU5EV core board is built around Xilinx's Zynq UltraScale+ MPSoC XCZU5EV‑2SFVC784 I, integrating four ARM Cortex‑A53 cores, two Cortex‑R5 cores, DDR4, QSPI and eMMC flash, and a rich set of high‑speed and peripheral interfaces. The board measures 80 × 60 mm and provides extensive I/O for secondary development.
The document provides an introduction to the board, detailed descriptions of the Zynq chip, DDR4 memory, QSPI and eMMC flash, clock configuration, LED indicators, power management, mechanical layout, and connector pin definitions, along with extensive pin‑out tables for DDR4 and the J32 connector. This manual is written in Chinese.
