This manual details the hardware configuration, power design, and usage of the Alinx AX309 FPGA development board featuring a Xilinx Spartan-6 chip.
The Alinx AX309 is an entry-level FPGA development platform designed for beginners. It features a Xilinx XC6SLX9-2FTG256C Spartan-6 FPGA in a 256-pin FBGA package, providing 9152 logic cells and 16 DSP48 multipliers.
The board includes various peripherals such as 256Mbit SDRAM, 16Mbit QSPI Flash, a VGA interface, an SD card slot, and two standard AX expansion ports. It is powered via USB through LDO regulators to generate the required +3.3V and +1.2V voltages for the FPGA core and I/O banks. This manual is written in Chinese.
| FPGA Model | XC6SLX9-2FTG256C |
|---|---|
| Logic Cells | 9152 |
| DSP48 Multipliers | 16 |
| Block RAM | 576Kb |
| Available IOs | 200 |
| Operating Temperature | 0-85℃ |
| Core Voltage | 1.2V (Recommended) |
The board uses a Xilinx Spartan-6 series chip, specifically the XC6SLX9 model.
The development board is powered via USB using a MINI USB cable connected to a computer.
The IO pins on the expansion ports operate at 3.3V logic level.
Yes, it includes a camera interface that can connect to an OV5640 camera.
