Key facts
- Manuals
- 4
- Languages
- ZH · EN
- Last added
- 2026-10-01
Featured Alinx manuals
Alinx ACU5EV Core Board User Manual
The ACU5EV core board is built around Xilinx's Zynq UltraScale+ MPSoC XCZU5EV‑2SFVC784 I, integrating four ARM Cortex‑A53 cores, two Cortex‑R5 cores, DDR4, QSPI and eMMC flash, and a rich set of high‑speed and peripheral interfaces. The board measures 80 × 60 mm and provides extensive I/O for secondary development.
The document provides an introduction to the board, detailed descriptions of the Zynq chip, DDR4 memory, QSPI and eMMC flash, clock configuration, LED indicators, power management, mechanical layout, and connector pin definitions, along with extensive pin‑out tables for DDR4 and the J32 connector. This manual is written in Chinese.
Covers: Introduction · ZYNQ Chip · DDR4 DRAM · QSPI Flash · eMMC Flash · Clock Configuration
Alinx P1 Logic Analyzer User Manual
The manual introduces the PlayLogic logic analyzer series, focusing on the P1 model. It details hardware specifications, supported protocols, and the PlayLogic software installation and interface.
It then explains how to connect the analyzer to a PC and the target system, provides step‑by‑step usage instructions, protocol configuration, data export, and a FAQ section addressing common connection and measurement issues. This manual is written in Chinese.
Covers: Product Introduction · PlayLogic Software Overview · Device Connection · Operation Details · Standard Protocol Settings · Frequently Asked Questions
Alinx AXU 5EV-E FPGA Development Board User Manual
The Alinx AXU 5EV-E board is a compact FPGA development platform built around a Xilinx Zynq UltraScale+ MPSoC (XCZU5EV‑2SFVC784I). It integrates a 4 GB DDR4 memory subsystem on the processing system side, a 1 GB DDR4 on the programmable logic side, 256 Mbit QSPI flash, 8 GB eMMC flash and a variety of high‑speed interfaces such as USB 3.0, PCIe Gen2, Gigabit Ethernet and HDMI.
The board measures only 3.15 × 2.36 inches and provides four board‑to‑board connectors that expose PS MIO, MGT transceivers, USB, Ethernet, SD, and many GPIOs. Power is split into four domains (Full, Low, PL, Battery) and the design includes on‑board temperature and voltage monitoring.
Covers: Introduction · ZYNQ Chip · DDR4 DRAM · QSPI Flash · eMMC Flash · Clock Configuration
Alinx AC7Z035 Development Board User Manual
The AC7Z035 core board is built around Xilinx's Zynq‑7000 series XC7Z035‑2FFG676 SoC, which combines a dual‑core ARM Cortex‑A9 processor with a rich FPGA fabric. The document describes the chip architecture, programmable logic resources and the board's overall layout.
Key hardware features include four 512 MB Micron DDR3 chips (4 GB total), two 256 Mbit QSPI Flash devices, an 8 GB eMMC, multiple USB, Gigabit Ethernet, SD/SDIO, I2C, CAN and UART interfaces, as well as eight high‑speed GTX transceivers. The board measures 80 mm × 60 mm and provides extensive I/O through 144 PL pins and four board‑to‑board connectors. This manual is written in Chinese.
Covers: Introduction · Zynq Chip · DDR3 DRAM · QSPI Flash · eMMC Flash · Clock Configuration
Latest Alinx manuals
Alinx ACU5EV Core Board User Manual
User Manual 27 pages · 1.6 MB · ZHThe manual details the ACU5EV core board based on Xilinx Zynq UltraScale+ MPSoC, covering hardware components, interfaces, and configuration.
Alinx P1 Logic Analyzer User Manual
User Manual 35 pages · 2 MB · ZHUser manual for the Alinx P1 logic analyzer covering product specs, software installation, device connection, operation, protocol settings and troubleshooting.
Alinx AXU 5EV-E FPGA Development Board User Manual
User Manual 29 pages · 1.2 MB · ENUser manual for the Alinx AXU 5EV-E FPGA development board, covering hardware overview, memory, interfaces and connector pin‑assignments.
Alinx AC7Z035 Development Board User Manual
User Manual 32 pages · 2 MB · ZHThe Alinx AC7Z035 development board user manual provides details on the Zynq‑7000 chip, DDR3, QSPI, eMMC, clock setup, LEDs, power and connector pin…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Alinx manuals
How much DDR4 memory is available on the processing system side?
The PS side has four 1 GB DDR4 chips, providing a total of 4 GB of memory.
What power‑supply sections does the board support?
The design supports a four‑part power division: Full, Low, PL and Battery domains.
What processor does the AC7Z035 board use?
It uses a Xilinx Zynq‑7000 series XC7Z035‑2FFG676 chip with dual ARM Cortex‑A9 processors.
What interfaces are provided on the AC7Z035 board?
The board includes USB, Gigabit Ethernet, SD/SDIO, I2C, CAN, UART, GPIO and eight high‑speed GTX transceivers.
