This manual describes the Alinx M2CG/M3EG/M4EV/M5EV core boards based on Zynq UltraScale+ MPSoCs, detailing hardware specifications, pin definitions, and…
The document introduces the M-series stamp-hole core boards (M2CG, M3EG, M4EV, M5EV) manufactured by Alinx. These boards are built around Xilinx Zynq UltraScale+ MPSoC chips (XCZU2CG, XCZU3EG, XCZU4EV, XCZU5EV) and feature 4GB of DDR4 memory, QSPI Flash, and eMMC Flash for storage and boot configuration.
The manual provides detailed technical information on the board's components, including the MPSOC chip architecture, DDR4 configuration, clock settings, Ethernet and USB interfaces, and power supply. It also includes a structural overview and a comprehensive pinout definition for the stamp-hole expansion connector, suitable for secondary development. This manual is written in Chinese.
| Processor Architecture | XCZU2CG: 2x ARM Cortex-A53; XCZU3EG/4EV/5EV: 4x ARM Cortex-A53 |
|---|---|
| CPU Speed | 1.2Ghz |
| Secondary CPU | 2x Cortex-R5 at 500Mhz |
| Memory Capacity | 4GB |
| Memory Speed | 1200MHz (2400 Mbps) |
| DDR4 Chip Model | MT40A512M16LY-062E |
| QSPI Flash Size | 256MBit |
| eMMC Flash Size | 8GB |
| Board Dimensions | 70*50 mm |
The boards support XCZU2CG, XCZU3EG, XCZU4EV, and XCZU5EV chips.
The DDR4 SDRAM can operate at a maximum speed of 1200MHz.
The board provides a total capacity of 4GB.
