The Alinx AC7Z035 development board user manual provides details on the Zynq‑7000 chip, DDR3, QSPI, eMMC, clock setup, LEDs, power and connector pin…
The AC7Z035 core board is built around Xilinx's Zynq‑7000 series XC7Z035‑2FFG676 SoC, which combines a dual‑core ARM Cortex‑A9 processor with a rich FPGA fabric. The document describes the chip architecture, programmable logic resources and the board's overall layout.
Key hardware features include four 512 MB Micron DDR3 chips (4 GB total), two 256 Mbit QSPI Flash devices, an 8 GB eMMC, multiple USB, Gigabit Ethernet, SD/SDIO, I2C, CAN and UART interfaces, as well as eight high‑speed GTX transceivers. The board measures 80 mm × 60 mm and provides extensive I/O through 144 PL pins and four board‑to‑board connectors. This manual is written in Chinese.
| SoC model | XC7Z035-2FFG676 |
|---|---|
| PS DDR3 speed | 533 MHz (1066 Mbps) |
| PL DDR3 speed | 800 MHz (1600 Mbps) |
| QSPI Flash | 2 × 256 Mbit |
| eMMC Flash | 8 GB |
| Logic cells | 275 K |
| LUTs | 171,900 |
| Flip‑flops | 343,800 |
| Block RAM | 17.6 Mb |
| GTX transceivers | 8 high‑speed channels |
| Board dimensions | 80 mm × 60 mm |
It uses a Xilinx Zynq‑7000 series XC7Z035‑2FFG676 chip with dual ARM Cortex‑A9 processors.
The board includes USB, Gigabit Ethernet, SD/SDIO, I2C, CAN, UART, GPIO and eight high‑speed GTX transceivers.
