The FJV992 is a PNP type silicon transistor produced by Fairchild Semiconductor Corporation. Its maximum collector-emitter voltage is -120V, maximum collector-base voltage is -120V, maximum emitter-base voltage is -5V, maximum collector current is -50mA, maximum collector power dissipation is 300mW, maximum junction temperature is 150°C, and maximum storage temperature is -55~150°C.
The document describes the Fairchild FJV992, a PNP epitaxial silicon transistor designed as an audio frequency low noise amplifier. It serves as a complement to the FJV1845 model and is packaged in a 4-pin SOT-23 package with pins designated for Base, Emitter, and Collector.
| Emitter-Base Voltage | 5 V |
|---|---|
| Collector Current (Ic) | -50 mA |
| Collector Power Dissipation (Po) | 300 mW |
| Junction Temperature (Tj) | 150 °C |
The current gain bandwidth product (fT) is 50 MHz.
The device is available in a 4-pin SOT-23 package.
