This document describes the FDC604P P-Channel MOSFET, which uses Fairchild's low voltage PowerTrench process and is suitable for battery power management applications. It features -5.5A, -20V, fast switching speed, and extremely low RDS(ON).
The Fairchild Semiconductor FDC604P is a P-Channel MOSFET utilizing the company's low voltage PowerTrench process. It is specifically optimized for battery power management applications, serving as a load switch or battery protection device. The device features a specified current of -5.5A and a voltage rating of -20V.
| Drain-Source Voltage | -20 V |
|---|---|
| Gate-Source Voltage | +8 V |
| Continuous Drain Current | -5.5 A |
| Maximum Power Dissipation | 1.6 W |
| Operating Junction Temperature Range | -55 to +150 °C |
| Static Drain-Source On-Resistance | 33 mΩ @ Vgs = -4.5 V |
| Package Marking | 604 |
The device is optimized for battery power management applications, specifically serving as a load switch or for battery protection.
The maximum continuous drain current is rated at 5.5 A.
The maximum power dissipation is 1.6 W.
